Dimensions
| 50282 600 x 600 mm (2 x 2 ft) |
50482 1200 x 600 mm (4 x 2 ft) |
50484 1200 x 1200 mm (4 x 4 ft) |
|
|---|---|---|---|
| Width | 1600 mm (63 in) | 2200 mm (87 in) | 2200 mm (87 in) |
| Depth | 1500 mm (60 in) | 1500 mm (60 in) | 1500 mm (60 in) |
| Height | 1400 mm (55 in) | 1400 mm (55 in) | 1400 mm (55 in) |
| Weight* | 1000 kg (2205 lb) | 1050 kg (2315 lb) | 1100 kg (2425 lb) |
*Weights are approximate and exclude packaging/shipping.
Specifications are subject to change without notice.
Test conditions apply using standard Labcut blades.
Material Capacity
| 50282 600 x 600 mm (2 x 2 ft) |
50482 1200 x 600 mm (4 x 2 ft) |
50484 1200 x 1200 mm (4 x 4 ft) |
|
|---|---|---|---|
| Cleared Panel Size | 600 x 600 mm | 1200 x 600 mm | 1200 x 1200 mm |
| Material Thickness/Cut depth | 0-55 mm | 0-55 mm | 0-55 mm |
| Cross cut travel X axis | 900 mm | 1550 mm | 1550 mm |
| Fence Travel Y axis | 600 mm | 600 mm | 1200 mm |
| Front specimen table size | 400 mm | 400 mm | 400 mm |
| Coolant Capability | Tracking Coolant/Bag Filter System | Tracking Coolant/Bag Filter System | Tracking Coolant/Bag Filter System |
Specifications are subject to change without notice.
Test conditions apply using standard Labcut blades.
Spindle
| 50282 600 x 600 mm (2 x 2 ft) |
50482 1250 x 600 mm (4 x 2 ft) |
50484 1250 x 1250 mm (4 x 4 ft) |
|
|---|---|---|---|
| Variable Speed | 2000-4500 RPM | 2000-4500 RPM | 2000-4500 RPM |
| Spindle Power | 2.4 kW | 2.4 kW | 2.4 kW |
| Blade Size | 250-300 mm | 250-300 mm | 250-300 mm |
| Blade Thickness | 1.5-4.0 mm | 1.5-4.0 mm | 1.5-4.0 mm |
Specifications are subject to change without notice.
Test conditions apply using standard Labcut blades.
Speed
| 50282 600 x 600 mm (2 x 2 ft) |
50482 1200 x 600 mm (4 x 2 ft) |
50484 1200 x 1200 mm (4 x 4 ft) |
|
|---|---|---|---|
| Rapid Speeds X,Y,Z | 120 mm/s | 80 mm/s / 100 mm/s | 80 mm/s |
| Cutting Speed | 0.1-40 mm/s | 0.1-40 mm/s | 0.1-40 mm/s |
Specifications are subject to change without notice.
Test conditions apply using standard Labcut blades.
Accuracy, Perpendicularity & Parallelism
| 50282 600 x 600 mm (2 x 2 ft) |
50482 1200 x 600 mm (4 x 2 ft) |
50484 1200 x 1200 mm (4 x 4 ft) |
|
|---|---|---|---|
| Typical Specimen Perpendicularity / 100 mm | 0.02 mm | 0.02 mm | 0.02 mm |
| Typical Specimen Parallelism / 100 mm | 0.02 mm | 0.02 mm | 0.02 mm |
| Typical Specimen Parallelism / 300 mm | 0.03 mm | 0.03 mm | 0.03 mm |
| Typical Specimen Parallelism / Panel | 0.06 mm | 0.06 mm | 0.06 mm |
| Typical Specimen Dimensional Accuracy | 0.03/100 mm | 0.03/100 mm | 0.03/100 mm |
| Typical Specimen Dimensional Accuracy | 0.05/600 mm | 0.05/600 mm | 0.05/600 mm |
| Typical Specimen Parallelism in Z plane | 0.05/55 mm | 0.05/55 mm | 0.05/55 mm |
Specifications are subject to change without notice.
Test conditions apply using standard Labcut blades.
Required Services
| 50282 600 x 600 mm (2 x 2 ft) |
50482 1200 x 600 mm (4 x 2 ft) |
50484 1200 x 1200 mm (4 x 4 ft) |
|
|---|---|---|---|
| Power | 415 V 3 Ph 32 Amp | 415 V 3 Ph 32 Amp | 415 V 3 Ph 32 Amp |
| Air - Dried & Filtered | 70-100 PSI | 70-100 PSI | 70-100 PSI |
| Extraction | Application Specific | Application Specific | Application Specific |
Specifications are subject to change without notice.
Test conditions apply using standard Labcut blades.
